Installation 41
Cod.nº 429043
Rev. No. 21/0519
HS-6024/HS-6028/HS-6032 models
• Disconnect and mechanically lock the external automatic switch.
• Open the machine’s top cover.
• Connect the voltage selector switch (Fig. 3.10) in accordance with the mains power supply and the following
table (Table 2).
Fig. 3.9
Table 2
Mains voltage:
Voltage selector
200V
200V-208V
208V
200V-208V
220V
220V-230V-240V
230V
220V-230V-240V
240V
220V-230V-240V
380V
380V-400V
400V
380V-400V
415V
415V
440V
440V-480V
480V
440V-480V
Fig. 3.10
