Technical specifications 7
Cod.nº 429043
Rev. No. 21/0519
1. TECHNICAL SPECIFICATIONS
1.1. Tools needed for installation
HS-6013; HS-6017; EH030; EH040
• Shipping restraints ............................ open end wrench 11/16 inch. (17mm)
• Shipping restraints ............................ tubular wrench 11/16 inch. (17mm)
HS-6023; HS-6024; HS-6028; HS-6032; EH055; EH060; EH070; EH080
• Shipping restraints ............................ open end wrench ¾ inch. (19mm)
• Shipping restraints ............................ offset ring wrench 3/4 inch. (19 mm)
• Shipping restraints ............................ tubular wrench 3/4 in. (19 mm)
Common to all models
• Clamps .............................................. nut driver 7mm
• Water inlet filters ............................... open end wrench 1 3/8 inch. (34mm)
• Covers fixing ..................................... open end wrench 1/2 inch. (13mm)
• Water inlet hoses .............................. slip-joint pliers or pipe wrench diam. 1 1/2 in (35 mm )
• Covers fixing ..................................... TORX T25 screwdriver
• Covers fixing .................................... TORX T20 screwdriver.
• Electrical requirements ................... Phillips 2 screwdriver (#2).
• External dosing connection .............. slotted-head screwdriver 3mm.
• Vending circuit connection ................ slotted-head screwdriver 3mm & Philips 1 (#1)
1.2. Accessories in machine
Keep all machine instructions in a safe place.
ACCESSORIES QUANTITY NOTES
Drain hose ................................................. 1
Drain clamp ............................................... 1
Cold water inlet hose (1) .......................... 1
Hot water inlet hose (1)
............................ 1 (2)
Water inlet couplings ................................. 2 (3)
Water inlet filter ......................................... 2 (3)
Water inlet hoses gaskets ......................... 6 (4) (5)
Steam inlet filter and valve (6) ................... 1
Water inlet coupling (7) ............................. 1
Top cover key ............................................ 1
Coin meter box key (8) (10) ....................... 1
Coin meter tokens (8) (10) ....................... 10
Fuses ......................................................... (9)
Installation handbook ................................ 1
Operation handbook .................................. 1
Parts handbook (1) .................................... 1
Documentation ......................................... (10)
(1) not available USA / Canada
(2) machines with third water inlet: 2 units
(3) machines with third water inlet: 3 units
(4)
machines no USA/Canada with third water
inlet: 9 units
(5)
machines USA/Canada 2 units, with third
water inlet: 3 units
(6) steam heating machines
(7)
only machines in USA / Canada with
steam heating
(8) Coin control models only
(9) depending on model and voltage
(10) depending on target country
