GIRBAU HS-6032 - Connection Table Explanation

Technical specifications 19
Cod.nº 429043
Rev. No. 21/0519
Environment and positioning conditions
MAXIMUM TEMPERATURE
ºC (ºF)
+41 (+104)
MINIMUM TEMPERATURE
ºC (ºF)
+5 (+40)
LIGHTING
Lux
300
VENTING OPENING
cm
2
(sq.ft.)
300 (0.4)
MAXIMUM RELATIVE HUMIDITY
%
90
S
WORKING AREA
mm (in)
1000 (39.4)
T
REAR MAINTENANCE AREA (*3)
mm (in)
500 (19.7)
*3. Double drain kit washers: figure T must measure 600 mm (23.6 inch) minimum
If the installation calls for more than one washer, please refer to the corresponding dimensions in section 2.5
and figure 2.3
1.5. Connection table explanation
Connection table explanation and symbols of section 1.6.
(*1) HEATING
(*2) EXPLANATION OF WIRE VALUES
H
Without heating
A
x B + N +
Wire details in mm2
V
Steam heating
(
A
x B + GND)
(USA/CANADA: wire details in AWG)
E
Electric heating
A x
B
+ N +
Wire number
red. reduced power
A x B +
N
+
Neutral wire
norm. normal power
A x B + N +
Ground
(A x B + GND)
(USA/CANADA: ground wire)
USE COPPER CONDUCTORS ONLY
The machine shall be connected only to a supply circuit to
which no lighting units or general-purpose receptacles are
connected.
