MULTIBEAM LENS DATA
The GJD multifunction lens fitted to the OPAL RFX detector produces 9 long range
beams and 9 medium to short range curtain beams. Movement across the beams
produces the best response and range, whilst movement towards the detector will be
less responsive.
When mounting higher than boundary fences rotate the module and mask off any
beams, either vertically or horizontally, that fall outside the area being covered. Use the
self-adhesive clear mask supplied to the rear, smooth side, of the lens and always
replace the correct way up as shown to obtain the exact beam pattern coverage.
Bea m Pattern set to minimum
range. M asking top section of
le ns wi ll reduce ra nge to 8 met r e s
Bea m Pa ttern set to m axim u m
range. M asking top section of lens
w ill redu ce ran g e to 2 0 metre s
TOP
MASK THIS SECTION OFF
FOR PET ALLEY
APPLICATIONS
UP TO 35 METRES
TOP
0 5 10 15
TOP
30 35
3
10 20
0deg
0
LONG RANGE 35 METRE SECTION
6TO20METRESSECTION
MU LTIBEAM - OPTIMU M
HEIGHT: 3 METRES
RAN GE: M AXIMUM
MO DULE TILT: 0 DEGREE
6
10 20 30 35
9deg
0
6 TO 20 METRES SECTION
MU LTIBEAM
HEIGHT: 6 METRES
RAN GE: M AXIMUM
M O DU LE TILT: 9 D E GRE E
1.5
10 20 30 35
-2 deg
0
PET IMM U N ITY
HEIGHT: 1.5 METRES
RAN GE: M AXIMUM
M O DU LE TILT: -2 D EG RE E
5 101520253035
15
10
5
0
5
10
15
02468101214
6
4
2
0
2
4
6
6
45deg
5
0
TOP
MASK THIS SECTION OFF
FOR CURTAIN COVERAGE
APPLICATIONS
CURTAIN COV ERAGE
HEIGHT: 6 METRES
RAN GE: M AXIMUM
MO DULE TILT: 45 DEG REE
