Glamox ITNSL-01T - 1.2 Design

POWER/
SYSTEM
FAILURE
MAIN
SUPPLY
SPARE
SUPPLY
POWER
ON / OFF
www.glamox.com/gmo
1
3
4
5
2
7
6
8
9
10
11
1 7
2 8
3 9
4 10
5 11
6 12
Touch screen display Buzzer
12
Power/system failure indication LED Rating plate
Main power supply indication LED Holders for fixing cables
Spare power supply indication LED Earth bolt
Power on/off push button DB9 connectors for inteface to power supply module
Clasp pin for mounting clamps Fuse
Main unit
1.2 Design
4
