Key Ring
Handset
The
hand transmitter
is manufactured
using the
latest
surface
mount
technology
and
incorporates
3 functional buttons.
This enables
the
user
to remotely control up
to 3 separate
operators
from
the one
handset"
The
soft
touch silicon
buttons
have been
irnpregnated
with a
"
night
glow"
material
for
easier
visibility.
Alarm
Closure
lf an
attempt
is
made to force
open the door
from
a
closed
position.
The
Glidermatic
Controller
will Pulse operate
the
door
to the
fully closed
position.
Remote switeh
A simple
Bell
Press type
momentary switch
can be
hard wired
directly
to
the
control board.
ACCESSORY
OPTIONS
With
the
installation
of
a small accessory board
the
Glidermatrc
Controller
can
perform
the
following
functions:-
External
Light
This
accessory
option
will allow
the connection of
auxiliary
lighting
ie drive way
lighting,
internal
garage
lights.
NB: Max.
Load
100W
IWARNING
All mains
lighting
must
be
fitted by a
qualified
Electrician
/
Personnel
External
Counter
For cemmercial
applisatlons
an
electroryc
e=o=,unte-r.
(for
door operations
)
can
be used
for warranty
verification.
LocalAlarm
A Piezo
Alarm
Siren can
be
fitted as a local
intruder alert.
This
will be
activated
if an attempt
is made to force open
the
door
from the
fully closed
position.
ln conjunction the
door
will
perform
an Alarm
Closure
*.
T?ris
output
can
also be
wired into an existing
home
alarm
systern.
*
Alarm closui'e
as
above.
External
LED Indicator"
An LED
panel
is fitted
within
the house
(hard
wired
)
to
show
the
status
of the
door ie open or
closed.
OPERATING
cCINTRaLS
ffig.
9)
1) Control
Box
Push Button
Pressing
this
button
will open, close
or stop the door.
2) Hand
transmitter
Nominally
for
a single door
installation
only the large
elliptical
button
is
programmed
to operate the
door, a
momentary
press
of
this button
will
open
,
close,
or
stoo
the door.
Note:
The standard
Glidermatic
handset
has
three
f ully
functional
and
independent buttons.
Thrs allows
the
handsei
to operate
up to
three opeilers
in
the
Gliderol
series
ie F,ciler
Llcr:r"
Cpenr:r,
(GRD)
Tiir. arrC Secticnal
Opener,
(GTS)
and
the Comnrandoor
2 Gate Opener.
GRD
OWNERS
MANUAL
PAGE 7
INTERNAL CONTROLS / CONNECTIONS
3) Courtesy
Lamp
This is a 9 Watt 24VDC Globe
which is turned on after
each activation
of the Control Box.
The illumination
period
is
approximately
60 seconds.
4) Obstruction
Detection
(overload)
Thrs adjustment
pot
allows
you
to increase or
decrease the amount
force required on a moving
door to register an overload condition.
5) Fuse
This is an automotive blade tvoe
fuse.
15A
(Blue)
6) Operation Switch
(
During Set Up Only
)
This
PCB mounted switch
will
allow
you
to operate
the controller
whilst the
front cover has been
removed, enabling
you
to complete
the set up
adlustments and
test the unit.
7) Internal
Pigzo Buzzer
(
enable/disable
)
The Piezo Buzzer is factory set
in the enabled
mode.
To disable
remove the
jumper
pin
(as
shown
in
diagram
9)
B)
Code Learning
This button is used to
store and delete
transmitter(s)
from the
on
board
memory.
The memory
will allow up to a
maximum of
10
handsets to be,,recorded,
lf more than 10 handsets
are learnt the
FIFO
(
First
In
First Out
)
system applres
ie first code
learnt will be
deleted and renlarpd
hv thp latest rode
learnt.
8a)
Learn LED lndicator
9)
Automatic Close
O Posrtron
Auto
-
Close disabled.
'1
Auto Close enabled
5 sec. delay
2
Auto Close enabled
1
5 sec.
delay
3 Auto Close enabled
20 sec. delay
4 Auto Close enabled
30 sec. delay
5 Auto Close
enableci
40
sec.
delay
6 Auto Close enabled
50 sec. delay
7 Auto CIose
enabled 60 sec.
delav
Please
Note :
Trme
delay will start once
the door
has fully opened
GLIDEROT
GARAEaDooRie
