INSTALLATION GUIDELINES
STEP 1: Orient Raceway Cover until it is almost VERTICAL and insert top of cover
into groove on panel.
STEP 2: Raceway Cover can be lifted up at 90 degrees, and pushed slightly into
panel, to lock in place.
STEP 3: Snap bottom corners of Raceway Covers, to secure into place.
STEP 1: Orient Raceway Cover until it is almost VERTICAL and insert top of cover
into groove on panel.
STEP 2: Raceway Cover can be lifted up at 90 degrees, and pushed slightly into
panel, to lock in place.
STEP 3: Snap bottom corners of Raceway Covers, to secure into place.
STEP 4: Raceway Covers lock securely in place on both ends, securing over black
tabs in panels.
Snap Raceway Knockout Covers into openings where duplexes are not being used.
Raceway Covers without Knockouts
Raceway Covers with Knockouts
Raceway Knockout Covers
