Section 3 Product Information
3-1
3.1 A-Series Surgical Operating Microscope Systems
The Surgical Operating Microscope is a system of modular components intended to improve ergonomics,
vision, and lighting during dental and medical procedures/examinations. If the options are chosen, the
microscope system may also aid in documentation. Components may include, but are not limited to, support
system, binoculars, objective lens, light source, beamsplitters, and video/photography systems. There are
four support system options to choose from to meet the clinician’s needs: a oor stand model, a oor mounted
model, a wall mounted model and a ceiling mounted model. All support system models provide maneuverability
and sturdy, stable support for the microscope and coupler arm assemblies. These systems fold into
convenient storage positions when not in use.
3.2 Microscope Support Systems Congurations
The A-Series Microscope Support System is available in four congurations:
Floor Stand Support System Model (M A730F) The oor stand support system model is designed for
portability around the ofce/examination room. It uses a compact H-Base with four large casters, occupying
minimal oor space. All four casters may be locked to prevent rolling. As the oor stand support system is
mobile, care must be taken to ensure safe transportation and to avoid any personal injury or damage to the
system.
M A730F
FLOOR STAND
shown with
M A730-HA Arm System,
M A1006 Microscope
M A1022-10 Binocular
M A1061-D50 Beamsplitter
M A1017 Carr Binocular Extender, 45°
M A1028-250 Objective Lens
