1. Product Information
Product Part I.D. EB-3531
Product Description:
The EB-3531 is a compact, high performance, low power consumption GPS engine board. It
features a SiRF Star III chipset, which can track up to 20 satellites at a time and perform fast
TTFF (time to first fix) in weak signal environments. The EB-3531 is ideal for automotive or
marine navigation, personal positioning, fleet management, and mobile-phone navigation.
Product Features
9 SiRF GSC3f/LP high performance GPS Chipset
9 Very high sensitivity (Tracking Sensitivity: -159 dBm)
9 Extremely fast TTFF (Time To First Fix) at low signal level
9 All-in-view 20-channel parallel processing
9 Two serial ports
9 4Mb flash
9 Built-in LNA
9 Compact size (15mm * 13mm * 2.2mm) suitable for space-sensitive application
9 One size component, easy to mount on another PCB board
9 Support NMEA 0183 and SiRF binary protocol
9 WAAS / EGNOS MSAS support
9 RoHS compliant
Product Specifications
GPS Receiver
Chipset SiRF GSC3f/LP
Frequency L1, 1575.42 MHz
Code C/A Code
Protocol NMEA 0183 v3.0
Default:GGA,GSA,GSV,RMC
Support:VTG,GLL,ZDA)
SiRF binary and NMEA Command
Available Baud Rate 4,800 to 57,600 bps adjustable
