9150-0125-01 R-4
ST150M User Manual
Confidential & Proprietary Information
37
6
RECOMMENDED OPERATING CONDITIONS
6.1
ABSOLUTE MAXIMUMS
Symbol
Parameter
Max
Units
V33_IN
Input Voltage Range for Digital Inputs
3.6
Volts
I33_IN
Input Current for Digital Inputs
100
mA
VRF_IN Input Voltage Range for RF circuitry 3.6 Volts
IRF_IN Input Current for RF Circuitry 500 mA
VUSB
Input Voltage Range for USB Device
5.25
Volts
PRF_IN_GPS
Input Power for GPS Receiver
0
dBm
PRF_IN_BLE Input Power for Bluetooth Transceiver +10 dBm
PRF_OUT_BLE
Output Power for Bluetooth Transceiver +8 dBm
PRF_OUT_TX
Output Power for Satellite Transmitter
+24
dBm
TA
Operating Ambient Temperature Range
85
°C
TS Storage Temperature Range 85 °C
Isolation between PRF_OUT_TX and PRF_IN_GPS 25 dB
6.2
HANDLING OF ELECTROSTATIC SENSITIVE DEVICES
Some components on the ST150M PCB are sensitive to electrostatic discharge (ESD). The following general guidelines can help
reduce damage due to ESD.
1.
Use a grounding bracelet if possible, to minimize charge build-up on personnel.
2.
Handle the ST150M PCB by the edges without touching components or printed circuit paths.
3.
Store the ST150M PCB in static sensitive packaging whenever possible.
NOTE:
Failure to adhere to ESD guidelines will void the product warranty.
6.3
WIRING
Proper installation and field wiring practices are important to follow. Users and installers
should familiarize themselves with the
requirements of all applicable codes, laws, and standards.
6.4
NOISE SOURCES
Electrical noise is an important consideration in any installation of the ST150M. When possible, sufficient physical separation
should be maintained between electrical noise sources and the ST150M.
