11
SP25 ELECTRICAL DIAGRAM - 120V SINGLE PHASE
ITEM DESCRIPTION QTY
C1 CAPACITOR 1
S1 EMERGENCY STOP BUTTON 1
S2 START BUTTON 1
S3 MICROSWITCH (INTERLOCK GUARD) 1
S4 MICROSWITCH (BOWL LIFT) 1
KM1 CONTACTOR COIL, 120V 60Hz 1
M1 MOTOR, 3/4 HP SINGLE PHASE 120V 1
LS1 CIRCUIT BREAKER 1
K1 TIMER 1
.0
/
1
3(
6
6
6
+3
0
a
.0
$ $
/6
6
(
.
.0
M)
9$&
&
