Globe SP40 - Important Points; Recommended Maintenance

Page8
Operating Instructions
 2.Torotatethebowlguardtoitsopenposition,grasptheseparatedhandlesonthebowlguardandmovethem,
 togetherasone,clockwisetoopen/rotatethebowlguard.Toclosethebowlguard,grasptheseparated
 handlesandmovethemtogetherasone,counterclockwisetoclose/rotatethebowlguardbackintoalocked
 position.
Removing and Attaching the Bowl Guard:
NOTE:Beforeremovingorattachingthebowlguard,makesurethebowlisinthedown/
loweredpositionandtheagitatortoolisofftheshaft.

 1.Toremovethebowlguardforcleaning,pushthelowerpartoftheseparatedhandle
 out(clockwise)dividingthehandleandreleasingtheguardfromtherotationring.
 (seeg.8-1)
 2.Onceseparated,takeholdofthelowerseparatedhandleandcontinueturningthe
 guardclockwiseuntilthebowlguardreleasesfromtheringcatchonthemixer.
 (seeg.8-2)
 3.Toreattachthebowlguard,lineuptheringcatchontheleftofthemixer;lift
 guardgentlyintoplaceandrotatetheguard’slowerhandlecounterclockwise
 untilitsnapsbackintoplacewiththeupperpartofthehandle.
ATTACHING THE BOWL TO THE MIXER
NOTE:InstallthebowlBEFOREattachingtheagitator.
1. Lowerthebowlbypullingthebowlliftleverforwardanddowntoitsresting
 position.FormodelsSP40andSP60rotatethebowlliftwheel
 counterclockwiseuntilitstops.FortheSP62PandSP80PLpressthedown
 arrow(bluebutton)tolowerthebowluntilitstops.
2. Liftthebowlbythebowlhandlesand:
 a. slowlypositionthelockingpin(locatedontherearofthebowl)intotheholeinthe
  middlerearofthecradle(seeg8-3).
 b. lowerthebowlontothepinslocatedoneithersideofthebowlcradle.
3. Oncethebowlispositionedonthecradle,securethebowlbypullingeachbowlclamp
 forwarduntilthebowlislockedtight(seeg8-4).
g.8-1
g.8-2
g.8-3 g.8-4
