8
2000221595
1 Technical Data
0
10
20
30
40
50
60
120010008006004002000
1
2
3
4
5
Pom 010 a
Flow rate through heating system (I/h)
(10 kPa = 1 m WG)
1
2
3 4
5
Bypass fully shut Open 1/4 turn Open 1/2 turn Open 1 turn Open 2 turns
PUMP 96
0
10
20
30
40
50
60
70
80
120010008006004002000
1
2
3
4
5
Pom 058
Available pressure (kPa) between
heating supply and return lines
PUMP 120
Flow rate through heating system (I/h)
Available pressure (kPa) between
heating supply and return lines
(10 kPa = 1 m WG)
Diagram 4
