GLP German Light Products GmbH instruction version 1.05 16
6 Technical Specifications
Power supply
Power consumption
350 VA (Watt)
Power Input
~100-240 V AC, 50-60 Hz (wide range input)
Fuse protection
Micro-fuse 5x20 mm, T 4A
Operational Parameters
Max. Ambient
Temperature
45°C (integrated overheating switch)
Mounting Position
Any (see chapter mounting)
Lighting System - Additive Color mixing
LED Type
90x Luxeon K2 High-power- LEDs
Lifetime
100.000 h
30 LEDs per color, wavelength optimized for maximum presentable color space
Optical System
High efficient Collimator cluster
Exchangeable optical carrier with 10° light distribution angle (25° optional)
Scattering light aperture
Shutter / Dimmer (8 Bit)
Strobe- Effect with variable speed between 1 - 10 flashes per second, Random-Strobe, Pulse-
Effects
Continuous Dimmer 0 - 100%
DMX Control
Standard USITT DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1.
Die DMX- Addressing starts at the DMX channel [001].
Pan / Tilt (8/16 Bit)
Pan- movement 660° in min. 3,2 seconds (Position Feedback)
Tilt- movement 300° in min. 1,5 seconds (Position Feedback)
Weights and Measures
Width of the base
340 mm
Length of the base
145 mm
height (head vertical)
370 mm
Weight (net)
7,5 kg
