GLP Impression Series - DMX Channel Selection (DMX Protocol)

GLP  German Light Products GmbH instruction version 1.05 12
4 DMX Channel Selection (DMX Protocol)
Normal- Mode 14 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° min. 3,2 s 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2,6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° min. 1,5 s 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1,2° (16 Bit) 0..255 00..FF 0..100
5) Color
Colors adjustable via RGB 0..7 00..07 0..2,5
(fixed)
Color 01 - Cyan 8..15 08..0F 3..5,5
Color 02 - Magenta 16..23 10..17 6..8,5
Color 03 - Yellow 24..31 18..1F 9..12,5
Color 04 - Lavender 32..39 20..27 13..15,5
Color 05 - Dark Lavender 40..47 28..2F 16..18,5
Color 06 - Amber 48..55 30..37 19..21,5
Color 07 - Deep Golden 56..63 38..3F 22..24,5
Color 08 - Dark Blue 64..71 40..47 25..27,5
Color 09 - Pink 72..79 48..4F 28..30,5
Color 10 - Lime Green 80..87 50..57 31..34,5
Color 11 - Light Blue 88..95 58..5F 35..37,5
Color 12 - Red 96..103 60..67 38..40,5
Color 13 - Green 104..111 68..6F 41..43,5
Color 14 - Blue 112..119 70..77 44..46,5
White 120..127 78..7F 47..49,5
Rainbow Effect slow - fast 128..255 80..FF 50..100
6) Red
Color mixing system - Red 0 - 100% 0..255 00..FF 0..100
7) Green
Color mixing system - Green 0 - 100% 0..255 00..FF 0..100
8) Blue
Color mixing system - Blue 0 - 100% 0..255 00..FF 0..100
9) Shutter
Shutter closed 0..15 00..0F 0..5,5
Random Strobe (different pattern) 16..47 10..2F 6..18,5
Strobe Pulse effect , slow - fast 48..79 30..4F 19..31,5
Strobe, slow - fast 1 Hz .. 10 Hz 80..239 50..EF 32..94,5
Shutter open 240..255 F0..FF 95..100
10) Dimmer
Dimmer (0% - 100%) 0..255 0..FF 0..100
11) Color
temperature
Continuous color temperature
correction between 7200k - 3200k
7200k - 3200k 0..255 0..FF 0..100
12) Special
Max. Power-Mode(*) Max. light output without
white balance
0..15 0..0F 0..5,5
White-Mode (*) White balance used 16..31 10..1F 6..12,5
Color1-Chaser C / C+1
slow – fast
0,7 BPS ... 2,3 BPS
=> 1,43 s ... 0,43 s
112..127 70..7F 44..49,5
Color1-Chaser C / C+2
slow – fast
0,7 BPS ... 2,0 BPS
=> 1,43 s ... 0,5 s
128..143 80..8F 50..56,5
Fan min. as long as temp. < 60°C 224..229 E0..E5 88..89,5
RESET 250..255 FA..FF 98..100
13) Move- No movement
0 00 0
ment Movement Size Phase
PAN 1 0° 01..01 01..01 0,5
1 90° 02..03 02..03 1,0
1 180° 04..05 04..05 1,7
1 270° 06..07 06..07 2,5
PAN 2 0° 08..09 08..09 3,3
