GLP German Light Products GmbH instruction version 1.05 13
Channel Function Time and Value DMX HEX %
2 90° 10..11 0A..0B 4,1
2 180° 12..13 0C..0D 4,9
2 270° 14..15 0E..0F 5,7
PAN 3 0° 16..17 11..11 6,5
3 90° 18..19 12..13 7,3
3 180° 20..21 14..15 8,0
3 270° 22..23 16..17 8,8
PAN 4 0° 24..25 18..19 9,6
4 90° 26..27 1A..1B 10,4
4 180° 28..29 1C..1D 11,2
4 270° 30..31 1E..1F 12
TILT size / phase see also PAN 32..63 20..3F 13..25
PAN / TILT size / phase see also PAN 64..95 40..5F 26..37
PAN / TILT (inverse) size / phase see also PAN 96..127 60..7F 38..50
Circle size / phase see also PAN 128..159 80..9F 51..62
Circle (inverse) size / phase see also PAN 160..191 A0..BF 63..75
lying eight size / phase see also PAN 192..223 C0..DF 76..87
random movement size see also PAN 224..255 E0..FF 88..100
14) Speed
Pan/Tilt relative movement 0..15 00..0F 0..6
Pan/Tilt
Pan/Tilt slow – fast
Use this channel 14) also for the speed
of the movements (channel 13).
Pan Min. 530° = 200 s
Pan Max. 530° = 2,65 s
Tilt Min. 285° = 110 s
Tilt Max. 285° = 1,8 s
16..255 10..FF 7..100
(*) Max. Power-Mode vs. White-Mode
The
I
I
M
M
P
P
R
R
E
E
S
S
S
S
I
I
O
O
N
N can regard the white-balance adjustments for each individual color setting.
Whether the White-Mode is used with RGB can be selected in the Normal DMX-Mode during
operation with the Special DMX channel. If the Special channel is set to a value between DMX 0..15,
the White-Mode is not used and the RGB goes for the maximum light output. If the Special channel is
set to a value between DMX 16..31, the white balance is used for the RGB output.
Since there is no Special DMX channel in the Compress DMX-Mode, the possibility exists to likewise
select these settings also in the display menu. Is the White-Mode set to “ON”, the white-balance is
activated. If the White-Mode is set to “OFF”, the RGB goes for the maximum light output (Max. Power-
Mode).
Compressed- Mode 10 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° min. 3,2 s 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2,6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° min. 1,5 s 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1,2° (16 Bit) 0..255 00..FF 0..100
5) Color
Colors adjustable via RGB 0..7 00..07 0..2,5
(fixed)
Color 01 - Cyan 8..15 08..0F 3..5,5
Color 02 - Magenta 16..23 10..17 6..8,5
Color 03 - Yellow 24..31 18..1F 9..12,5
Color 04 - Lavender 32..39 20..27 13..15,5
To Next Page
