GLP Impression Series - Page 14

GLP  German Light Products GmbH instruction version 1.05 14
Channel Function Time and Value DMX HEX %
Color 05 - Dark Lavender 40..47 28..2F 16..18,5
Color 06 - Amber 48..55 30..37 19..21,5
Color 07 - Deep Golden 56..63 38..3F 22..24,5
Color 08 - Dark Blue 64..71 40..47 25..27,5
Color 09 - Pink 72..79 48..4F 28..30,5
Color 10 - Lime Green 80..87 50..57 31..34,5
Color 11 - Light Blue 88..95 58..5F 35..37,5
Color 12 - Red 96..103 60..67 38..40,5
Color 13 - Green 104..111 68..6F 41..43,5
Color 14 - Blue 112..119 70..77 44..46,5
White 120..127 78..7F 47..49,5
Rainbow Effect slow - fast 128..255 80..FF 50..100
6) Red
Color mixing system - Red 0 - 100% 0..255 00..FF 0..100
7) Green
Color mixing system - Green 0 - 100% 0..255 00..FF 0..100
8) Blue
Color mixing system - Blue 0 - 100% 0..255 00..FF 0..100
9) Shutter
Shutter closed 0..15 00..0F 0..5,5
Random Strobe (different pattern) 16..47 10..2F 6..18,5
Pulse effect , slow - fast 48..79 30..4F 19..31,5
Strobe, slow - fast 1 Hz .. 10 Hz 80..239 50..EF 32..94,5
Shutter open 240...249 F0..F9 95..97,5
RESET Min. 3 Sec. 250 FA 98
Shutter open 251..255 FB..FF 99..100
10) Dimmer
Dimmer (0% - 100%) 0..255 0..FF 0..100
High Resolution- Mode 13 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° min. 3,2 s 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2,6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° min. 1,5 s 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1,2° (16 Bit) 0..255 00..FF 0..100
5) Red-
coarse
Color mixing system - red coarse
0 - 100% 0..255 00..FF 0..100
6) Red-fine
Color mixing system - red fine 0..255 00..FF 0..100
7) Green-
coarse
Color mixing system - green coarse
0 - 100% 0..255 00..FF 0..100
8) Green-
fine
Color mixing system - green fine
0..255 00..FF 0..100
9) Blue-
coarse
Color mixing system - blue coarse
0 - 100% 0..255 00..FF 0..100
10) Blue-fine Color mixing system - blue fine
0..255 00..FF 0..100
11) Shutter
Shutter closed 0..15 00..0F 0..5,5
Random Strobe (different pattern) 16..47 10..2F 6..18,5
Pulse effect , slow - fast 48..79 30..4F 19..31,5
Strobe, slow - fast 1 Hz .. 10 Hz 80..239 50..EF 32..94,5
Shutter open 240...249 F0..F9 95..97,5
RESET Min. 3 Sec. 250 FA 98
Shutter open 251..255 FB..FF 99..100
