Names and Functions
Transfer test results to computer(Cable is
optional.)
Data Port
Side View
Battery Cover
Slide cover off for replacing battery.
Rear View
8
Names and Functions
1. Indicates strip code number.
2. Displays current mode.
3. Warning when the battery is low or
need to be replaced.
4. Display test results and messages.
5. Indicate ready to test.
6. Indicates abnormal temperature
warning.
7. Display measuring unit.
8. Display current time.
9. Indicates alarm.
10. Display date and year.
Display
Lancing Device
Clear AST cap
Adjustable cap Lancet holder
Lancet ejector
Release button
Sliding barrel
9
AvgMe m
Set
mg/dL
am
pm
C
* Clear AST cap is an optional accessory.
Please contact your local distributor.
