Page 3
General Machine Products (KT), LLC
CONTENTS
SECTION DESCRIPTION PAGE
1.0 INTRODUCTION 4
2.0 SAFETY INSTRUCTIONS 5
2.1 WORK AREA AND GENERAL SAFETY 5
2.2 GENERAL PNEUMATIC SAFETY INSTRUCTIONS 7
2.3 GENERAL ELECTRICAL SAFETY INSTRUCTIONS 7
3.0 CRITICAL POINTS THAT AFFECT THE CABLE BLOWING MACHINE 7
4.0 GENERAL DESCRIPTION 9
5.0 SPECIFICATION 9
6.0 EQUIPEMENT LAYOUT 10
6.1 BLOWING MACHINE LAYOUT 10
6.2 REMOTE CONTROL LAYOUT 11
7.0 OPERATING PROCEDURE 11
7.1 SETTING UP BLOWING AREA 11
7.2 CHANGING THE DUCT CLAMPS AND CABLE GUIDES 12
7.3 DUCT AND CABLE SET UP 12
7.4 SETTING THE CLAMP FORCE 13
7.5 CONNECT THE AIR SUPPLY TO THE MACHINE 14
7.6 CONNECTING THE REMOTE AND ELECTRICAL SUPPLY 14
7.7 CABLE INSTALLATION 15
7.8 OTHER REMOTE FUNCTIONS 18
7.9 DATA LOGGING 19
8.0 MAINTENANCE 20
8.1 GENERAL 20
8.2 REPLACING THE AIRBOX HOUSING SEAL 21
8.3 CHANGING THE CABLE DRIVE BELTS 21
8.4 TENSIONING THE DRIVE BELTS 22
8.5 CHANGING THE NYLON CABLE GUIDE 23
9.0 MONTHLY SERVICE CHECK LIST 23
9.1 SERVICE HISTORY RECORD 24
10.0 DUCT INTEGRITY 25
10.1 DUCT LUBRICATION 26
11.0 RECOMMENDED SPARES LIST 27
12.0 APPENDIX 1- COLLET AND SEAL LIST 28
13.0 APPENDIX 2- MAIN REMOTE SCREENS 29
13.1 MAIN SCREEN 29
13.2 PRE-INSTALLATION SCREEN 30
13.3 INSTALLATION SCREEN 30
13.4 SETTINGS SCREEN 31
13.5 SYSTEM INFORMATION SCREEN 31
13.6 ENVIRONMENT SCREENS 32
13.7 FILE STORAGE SCREEN 32
14.0 BLOWING ACCESSORIES 33
