Go Power GP-PWM-10-FM User Manual

GP-PWM-10-FM
4
© 2018 Go Power!
1.4 Low Voltage Disconnect Function (USB Port)
To protect the battery against over-discharge this function automatically
switches off the USB output port when battery voltage is lower than 11.0
VDC. As soon as the battery reaches a voltage of 12.8 VDC the USB
output port is switched on again.
1.5 Regulatory Information
1.6 Specifications
Description
Value
Dimensions
(H x W x D):
149 x 98 x 32 mm
5.87 x 3.86 x 1.26 in
Weight: 260 g / 9.2 oz
Maximum Wire Gauge:
#4 AWG
Warranty: 5 years
• PWM Charging
• 4 Battery Charging
Profiles
• 4-Stage Charging
• Monthly Equalize
Option
• Displays Charging
Current, Battery
Voltage, Battery State
of Charge, and Amp
Hours Charged Since
Last Reset
• Reverse Polarity
Protected
• Temperature
Model
GP-PWM-10-FM
Nominal System Voltage 12 VDC
Range of Battery Input
Voltage
9 – 15.5 VDC
Maximum Solar Continuous
DC Charge Current Input
12.5 ADC
Charging Output DC
Voltage Range
9 – 14.9 VDC
Maximum Solar DC Input
Voltage
35 VDC
Maximum Series Fuse or
Circuit Breaker
Solar/Battery
15 A
Operating Consumption
(Display backlight on)
15 mA
Operating Consumption
(Display backlight off)
6 mA
Battery Types Supported Vented & Sealed Lead Acid (GEL,
AGM, Flooded, etc.). Lithium
(LiFePO4)
