Go Power GP-PWM-10-FM User Manual

GP-PWM-10-FM
5
© 2018 Go Power!
Bulk/Absorption Voltage
(Sealed/GEL, AGM/LFP,
Flooded)
14.1/14.4/14.4 VDC
(25°C / 77°F), 30min / Day
or 2hr if battery voltage < 12.3 VDC
Compensated
• RoHS Compliant,
Environmentally Safe
• Accepts up to 160
Watts of Solar at 12
Volts
Float Voltage
13.7V (25°C / 77°F), 14.0V (LFP)
Equalization Voltage 14.9V (25°C / 77°F),
2h / 28 Days
or if battery voltage < 12.1 VDC
Temperature Compensation
- 24mV/ºC / -13mV/ºF
USB charger
5V, 1500mA
Low Voltage Disconnect
(USB)
11.0 VDC
Reconnects once battery reaches
12.8 VDC
Operating Temperature
- 40 to 85°C / - 40 to 185°F
Display Operating
Temperature
- 10 to 55°C / 14 to 131°F
Humidity
99% N.C.
Protection Battery Reverse Polarity, Solar Array
Reverse Polarity, Over Temperature,
PV Short Circuit, Over Current
2.0 IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
THIS MANUAL CONTAINS IMPORTANT INSTRUCTIONS FOR
MODEL GP-PWM-10-FM THAT SHOULD BE FOLLOWED
DURING INSTALLATION AND MAINTENANCE OF THE GP-
PWM-10-FM.
Disconnect all
power sources
Electricity can be very dangerous. Installation
should be performed only by a licensed
electrician or qualified personnel.
