Go Power IC Series User Manual

gpelectric.com | [page 47]
SPECIFICATIONS
Electrical Specication Item GP-IC-3000
Inverter
Mode
Input
Characteristics
Nominal Voltage 12 VDC
Absolute Max. DC Input 25 VDC
HBCO/HBCI 17 VDC ±0.3V
LBCO/LBCI 9.0 VDC ±0.3V
Input Voltage Range 9 - 17 VDC ±0.3V
Input Over-Voltage Protection 16.5 - 17 VDC
Input Under-Voltage Protection 9 - 10.5 VDC
Max DC Input Current 400 ADC
No Load Power Consumption 25W
Stand-By Power Consumption <5W
Output
Characteristics
Continuous Output Power 3000W
Surge Power
200 ms 6000W
5 sec 4800W
5 min 3300W
Frequency 60 Hz
Output Voltage
120 VAC +/-5%(
≦ Continuous Power)
MaxE󰀩ciency >90%
Short Circuit Protection Yes
Output Waveform Pure Sine Wave (THD <5% @ 12.5 VDC)
Charger
Mode
Charger
Characteristics
Battery Temperature Protection Yes
AC Input Voltage Range 80 - 140 VAC±5%
AC Input Frequency Range 50 - 70 Hz
AC Input Current Range 5 - 50A
AC Nominal Current 18A
ChargerPeakE󰀩ciency 85%
Power Factor Correction >0.97 (50% Load)
Charging Current Range 0 - 125 A
Battery Temperature Compensation 25 mV per °C
Four State Charging Bulk, Absorb, Final, Equalize
Equalization
Characteristics
Max Output Voltage 16 VDC
Max Output Current 10A
Bypass Relay RelaySpecication 50 Amp AC (per leg)
Operating Temperature
Range
Full Load -20°C to 40°C
Power De - Rating 60W per °C from 41°C - 60°C
Storage -30°C to 70°C
Over Temperature Protection Transformer, MOSFETs, Battery
Operating Humidity Range 0-95% Non-condensing
Ground Relay Default is Open (AC Pass-Through Mode)
Mechanical
Specication
Size (WxHxD)
12.6” x 8.07” x 13.7”
(321mm x 205mm x 349mm)
Net Weight 22.6 Kg (49.8 lbs)
Safety and EMC
Safety Standards
UL 458 & Supplement SA, UL 1741, CSA
22.2 No.107.1-01
EMC Standards FCC Class B

Go Power IC Series Specifications

General

Output Voltage	12 VDC
Battery Types	AGM, Gel, Flooded, Lithium
Protection Features	Over-voltage, Over-temperature
Operating Temperature	-4°F ~ 140°F (-20°C ~ 60°C)
Dimensions	Varies by model
Weight	Varies by model
