Bitmap fonts 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°, 270° rotatable
Asian fonts 0°, 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical
directions
Scalable fonts 0°, 90°, 180°, 270° rotatable
1-D Bar codes:
China Postal Code, Codabar, Code 11, Code 32,Code 39, Code 93, Code 128 (subset A, B, C),
EAN-8/EAN-13 (with 2 & 5 digits extension), EAN 128, FIM, German Post Code, GS1 DataBar,
HIBC, Industrial 2 of 5 , Interleaved 2-of-5 (I 2 of 5), Interleaved 2-of-5 with Shipping Bearer Bars,
ISBT-128, ITF 14, Japanese Postnet, Logmars, MSI, Postnet, Plessey, Planet 11 & 13 digit, RPS
128, Standard 2 of 5, Telepen, Matrix 2 of 5, UPC-A/UPC-E (with 2 or 5 digit extension),
UCC/EAN-128 K-Mart and Random Weight
2-D Bar codes:
Aztec code, Code 49,Codablock F , Datamatrix code, MaxiCode, Micro PDF417, Micro QR code,
PDF417,QR code, TLC 39, GS1 Composite
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode (UTF8, UTF16)
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from
the software
USB Device (B-Type)
Serial port: RS-232 (DB-9)
IEEE 802.3 10/100Base-Tx Ethernet port (RJ-45)
One Tri-color LED: Power (Green, Orange and Red)
Control key: FEED
Auto Switching 100-240VAC, 50-60Hz
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C)
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.
CE EMC, FCC Class A, CB, cUL
Length: 8.58” (218 mm)
Height: 6.53” (166 mm)
Width: 6.61” (168 mm)
3.3 lbs (1.5Kg) ,excluding consumables
Cutter Module
Label Dispenser
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
*选购项目请洽询原购买单位。上述规格若有变动，均以实际出货为主，恕不另行通知。以上所引
用之商标版权均属原公司所有。
**因应不同耗材特性，实际列印尺寸须视实际耗材适配而定。
***刀具为选购品，若有安装刀具，请勿让儿童接近。
