DT series User’s Manual
6
機種 DT4
下載字體
Bitmap fonts 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°, 270° rotatable
Asian fonts 0°, 90°, 180°, 270° rotatable and 8 times expandable in horizontal and
vertical directions
Scalable fonts 0°, 90°, 180°, 270° rotatable
條碼
1-D Bar codes:
Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5
with Shipping Bearer Bars,
Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart,
Random Weight,
Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and
Aztec code
碼頁
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode (UTF8, UTF16)
圖形處理
Resident graphic file types are BMP and PCX, other graphic formats are downloadable
from the software
傳輸介面
USB Device (B-Type)
Serial port: RS-232 (DB-9)
IEEE 802.3 10/100Base-Tx Ethernet port (RJ-45)
控制面板
One Tri-color LED: Power (Green, Orange and Red)
Control key: FEED
計時裝置 Standard
電源 Auto Switching 100-240VAC, 50-60Hz
工作環境
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C)
濕度
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.
安規 CE EMC, FCC Class A, CB, cUL
機體尺寸
Length: 8.58” (218 mm)
Height: 6.53” (166 mm)
Width: 6.61” (168 mm)
機體重量 3.3 lbs (1.5Kg) ,excluding consumables
選購項目
Cutter Module
Label Dispenser
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
*
選購項目請洽詢原購買單位。上述規格若有變動，均以實際出貨為主，恕不另行通知。以上所引用之商標版權均屬
公司所有。
**
因應不同耗材特性，實際列印尺寸須視實際耗材適配而定。
