When the print line is incorrectly set, the print quality on one side of the medium may suffer.
In such a case, the print line must be adjusted so it is positioned parallel to the paper feed roller.
Adjustment Methods
1. To move the print head in Direction-A as indicated by the red arrow, turn the adjustment screw anticlockwise
(see Arrow-1).
2. To move the print head in Direction-B as indicated by the red arrow, turn the adjustment screw clockwise
(see Arrow-2).
ADJUSTMENT SCREW
Screw for adjusting the printer line
Arrow-1
Turn the adjustment screw
Arrow-2
PRINT HEAD
Direction-A
Direction-B
