Godox LP75R - Page 18

ADD
Code
Operation
mode
CCT HSI RGBW
FX Filters
0-51 52-103 104-155 156-207 208-255
DMX*(100
/255) Integer
0-100%
Brightness
adjustment
0-255
n
1. Color Temperature Adjustment(e.g.
min. color temperature 2800,
min. color temperature 6500,
DMX=102,102*((6500-2800)/100)/255
=14 (corresponding color temperature
28+14=42*100=4200)
2. Hue adjustment
(e.g. DMX=200: H=200*360/255=282)
3. For example: total number of special
light effect 14, DMX=160, number of
light effect =160*14/255=8
n+1
DMX*(Max.
color
temperature-
min. color
temperature)
/100)/255)
Integer
n+2
0-127：
L-GEL
128-255：
R-GEL
0-255
Intensity
of red light
n+3
0-85：I
86-171：II
172-255：III
0-255
Intensity
of green light
n+4
0-255
Intensity
of blue light
n+5
0-255
Intensity
of white light
n+6
n+7
Please refer to the data sent by control center as follows:
Note
DMX*(100
/255) Integer
0-100%
Brightness
adjustment
DMX*(100
/255) Integer
0-100%
Brightness
adjustment
DMX*(100
/255) Integer
0-100%
Brightness
adjustment
DMX*(360
/255) Integer
Hue Selection
DMX*(Total
quantity of
light effects
/255)
DMX*(100
/255) Integer
G/M Setting
DMX*(100
/255)
Saturation
setting
DMX*( Total
quantity of
gels/255)
Integer
1. Hue adjustment (-50—0—50
corresponding value 0--100) e.g.
DMX=212,
GM mapped value=212*100/255=83
2. For example, the total quantity of
gels is 20, DMX=96：96*20/255=0
(gel 0)
Long press the LOCK button for 2 seconds
to lock or unlock the operation interface.
Icon will be displayed when being locked.
In MENU interface, turn the select dial
to choose fan and short press it to enter
fan interface. Then, turn the select dial
to choose turn on or off. Icon will be
displayed once turned off the fan and silent
mode will be achieved. When the silent
mode is turned on, the adjustable range of
brightness is 0%-50%.
Note: When using LEAD and FOLLOW modes through DMX port, the quantity of lights in
FOLLOW modes cannot be over 18.
ON
FAN
3.4.1 The default address is OFF, you can directly set a lamp as
the master mode (LEAD).
3.4.2 Set other lights as FOLLOW modes (no needs to set ADD).
3.4.3 Connect the lights with DMX connect cable.
3.4.4. The lights in FOLLOW modes will automatically synchronize the light in
LEAD mode.
3.4 DMX Port LEAD and FOLLOW Mode
4. Silent Mode
5. Locking function:
OFF
Note: The locking function only locks the control panel
function; the 2.4G wireless remote control, Bluetooth
control and the remote control of the DMX are not
affected.
LEAD
FOLLOW
01
FOLLOW
18
FOLLOW
...
FOLLOW
02
- 33 - - 34 -
