Gold's Gym Cycle Trainer 310 - Step 10: Console Wiring; Final Assembly Check

9
10
11. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly is
completed, some extra parts may be left over.
10. Slide the Console (20) onto the Console Mount
(19). Connect the wire on the Console to the
Reed Switch Wire (47) in the Frame (1).
20
19
1
47
Wire
