40
41
INDEX
Introduction........................................41
System characteristics ..........................41
Index .................................................41
Power supply installation.......................42
Door panel installation.................42 to 44
Access control description ....................45
Access control programming ....................
Programming methodes ....................45
Enter and exit from programming ........46
Programming structure and sequence.....46
Function fields and values ..........47 to 50
Duplicated codes..............................50
T-901 Telephone installation.................51
T-712VD Telephone installation.............52
Lock release installation .......................53
Important note.............................53
Starting recommendations....................53
System operation.................................53
Installation diagrams ...............................
Audio door entry system.......................54
2nd relay connection.........................55
Parallel telephones installation............55
External lock release activation ...........55
Quick programming guide ...................56
Troubleshooting hints...........................57
INTRODUCTION
First of all we would like to thank and congratulate you for the purchase of this product
manufactured by Golmar.
The commitment to reach the satisfaction of our customers is stated through the ISO-9001
certification and for the manufacturing of products like this one.
Its advanced technology and exacting quality control will do that customers and users enjoy with
the legion of features this system offers. To obtain the maximum profit of these features and a properly
wired installation, we kindly recommend you to expend a few minutes of your time to read this manual.
SYSTEM CHARACTERISTICS
O
O
O
O
O
O
O
Audio system with 4 + N wires installation.
O Just 1 TF-104 transformer (12Va.c., 1.5A).
O Electronic call with acoustic acknowledgement signal.
O a.c. lock releases activation.
O Up to three telephones in the same apartment.
O Access control module with numeric keypad.
2 output relays of 8 activation codes each and independent panic code.
4, 5 or 6 digits programmable codes.
Relay 1: n/c or n/o, single shoot or stable software programmable (60W maximum load).
Relay 2: single shoot with three contacts (n/c or n/o with 60W maximum load).
Programmable activation time from 1 to 20 seconds on single shoot mode.
After introduction of consecutive wrong codes, the access control is disabled (more information
on page 52, "System operation").
