golmar Stadio Plus - Fixing the Telephone; Description

erminal connector description.
T
positive, ground.
audio, digital communication.
intercom (only T-940 Plus).
auxiliary calling device output (only T-940 Plus).
door bell push button input.
+ , :
A , D :
INT :
SA :
HZ- :
–
A D
+
_
SAINT HZ-
ix the telephone.
F
It will be necessary to open the telephone for wiring and
fixing purposes. To open the telephone insert a plain
screwdriver into the slots and rotate it as shown.
Avoid to place the telephone near to
heating sources, in dusty locations or
smoky environments.
The telephone can be fixed using an
electrical embedding box or directly
on the wall, as shown on the picture.
If the telephone will be installed directly
over the wall, drill two holes of Ø6mm.
on the specified positions, using 6mm.
wallplugs and Ø3,5 x 25mm. screws.
Pass the installation wires through the corresponding hole and
connect them as shown on the installation diagrams.
Close the telephone as shown on the picture. Once the telephone
is closed, connect the handset using the telephone cord and
put it on the craddle.
103
T-940 TELEPHONE DESCRIPTION
T-940 TELEPHONE INSTALLATION
T-940 Plus:
T-940 Uno:
A D
+
_
HZ-
104
T-740 TELEPHONE DESCRIPTION
escription of the T-740 Uno telephone.
D
a
d
c
e
b
g
e
f
a.
b.
c.
d.
e.
f.
g.
If the handset is off the hook, allows to call to the master porter's
exchange.
During call reception and communication progresses allows
the lock release activation.
HZ-A D
+
_
+ , :
A :
D :
HZ- :
–
Telephone handset.
Speaker grille.
Microphone hole.
Subjection hole.
Telephone cord connectors.
Function push buttons.
Hook switch.
positive, ground.
audio communication.
digital communication.
door bell push button input.
erminal connector description.
T
unction push button.
F
