1 Safety Instructions
1.1 General Notes
• Read the including product documentation completely and carefully before
use. It is part of the product.
• Attend to the safety instructions in product documentation, on product and
accessories, such as on the package.
• Use product, product parts and accessories only in perfect condition.
• Keep the product documentation for other potential users and for later
requests.
• For questions, defects, mechanical damage, disturbances and other not
remediable problems, consult your dealer.
Risk of life by suffocating
Children can suffocate by swallowed or inhaled parts and insulation materials.
>> Protect small parts and insulation material against unintentionally use.
Risk of injury by tripping and falling
Unfavorable placed or installed products and cable connections can injure
persons.
>> Place, transport and install product, parts and acceories in a safe way.
>> When working with burdens, secure yourself and the working place, let a
second person help you.
>> Let only a specialist do disassembly, maintenance and repair work.
Risk of injury by cutting
Children can cut themselves on packaging materials.
>> Protect packaging materials against unintentionally use.
Risk of self-intervention and misuse
Self-interventions and misuse hide unpredictable risks and cause expiration of
warranty.
>> Donotmodifyoraltereithertheproductortheaccessories!
Risk of material damage by improper product combination
Incompatibleproductcombinationdoesnotfulllrequiredfunctions,cancause
quality losses or material damage.
>> Thespecicationsofallusedproductsmustmatchorbewithinthe
speciedrange.
>> Mind the mobility of the product during use. This may move away from
the wall or towards it and swivel sideways.
Risk of material damage by inappropriate ambient conditions
Incorrect ambient conditions can damage things.
>> Avoid extreme conditions, such as extreme heat, coldness, humidity or
direct exposure to the sun, as well as vibrations and mechanical pressure.
BETRIEBSANLEITUNG ............................................. 2
USER’S MANUAL
....................................................... 12
....................................................... 22
............................................ 32
Content
1 Safety Instructions ................................................................... 13
1.1 General Notes ..............................................................13
1.2 User Groups .................................................................14
1.3 Warning Levels ............................................................. 14
2 Description and Function ......................................................... 14
2.1 Scope of Delivery .........................................................14
2.2 Required tools ..............................................................15
3 Intended Use ............................................................................15
3.1 Use restrictions .............................................................15
4 Installing ...................................................................................16
4.1 Preparing ......................................................................16
4.2 TV wall mount installation.............................................16
4.3 Mountingtheatscreen ............................................... 17
4.3.1 TV wall mount is already installed ...............................18
4.3.2 TV wall mount is already not installed ......................... 18
4.3.3Mountinganarchedatscreen ................................... 19
5 Warranty and Liability ..............................................................19
6 Maintenance, Care, Storage and Transport ............................19
7 Specications...........................................................................20
8 Information for VESA standard ................................................20
9 Disposal Instructions ...............................................................20
