1.2 User Groups
Caused to different risk levels and hazard potentials some working steps only
may be done by trained specialists.
Working step User Group
Installing, Un-
installing, Care,
Storage, Trans-
port, Disposal
Consumers and users with basical mechanical knowledge
can do this work.
>> Protect children and people with mental and motoral
impairmentsfromusingtheproduct!
Maintenance,
Repairing
Trained specialists only
>> special safety measures, knowledge and tools are nec-
essary!
Ta b . 9 : User Groups
1.3 Warning Levels
Warnings against hazards that will result directly in serious injuries or death
in case of non-observance.
Warnings against hazards that may result in serious injuries or death in case
of nonobservance.
Warnings against hazards that may result in injuries in case of non-obser-
vance.
Warnings against hazards that may result in material damage in case of
non-observance.
2 Description and Function
Your VESA Adapter is used to extend your TV wall mount to the VESA dimensi-
ons 200x100 and 200x200mm. It comes with mounting hardware and is made
of powder coated steel.
2.1 Scope of Delivery
Part Figure Symbol Amount
TV wall mount installation
VESA Adapter A 1
M5x16 B 4
M5 Nut
C 4
Flat screen installation
M6x14 M-A 4
M8x20
M-B 4
Washer D8
M-C 4
TV Spacer
M-D 8
Ta b . 1 0 : Scope of Delivery
2.2 Required tools
Tool Figure
Phillips screwdriver
Wrench M8
second Person
Ta b . 11 : Required tools
3 Intended Use
Thisproductismadeformountingatscreenswithspecicscreensizes,
weights and mounting points, which are summarized in chapter “Technical data“,
on a vertical wall. Another use than described in chapter “Description and
Function“ is not permitted. Neglegting and ignoring these regulations and safety
instructions can cause serious accidents, personal injury and material damage.
Also refer to chapter “Warranty and Liability“.
3.1 Use restrictions
Only use in dry interior rooms.
