APPENDIX
UNIT DIMENSIONS
MEDIUM CHASSIS
GP*1324M4**
GP*1330M4**
GP*1336M4**
GP*1342M4**
LARGE CHASSIS
GP*1348M4**
GP*1360M4**
BLOWER
ACCESS PANEL
?
?
2 34
51
47
SUPPLY
1 3/8
A
RETURN
POWER
WIRE
ENTRANCE
4 1/8
2 1/8
6 ½
16
16
5 ½
B
B
CONTROL
WIRE
ENTRANCE
CONDENSATE
DRAIN
CONNECTION
3/4” NPT FEMALE
18 7/8
SUCTION/LIQUID
PRESSURE PORT
3
8
