PRoDUcT SPeciFicATionS
PRoDUcT SPeciFicATionS
SS-GPC13H www.goodmanmfg.com 3
SPeciFicATionS
GPC13
24H41AC
GPC13
30H41AA
GPC13
30H41AC
GPC13
36H41AA
GPC13
36H41AC
Total BTU/h 24,000 28,600 28,600 36,000 36,000
Sensible BTU/h 18,600 22,700 22,700 26,000 26,000
SEER / EER 13.0 / 11.0 13.0 / 11.0 13.0 / 11.0 13.0 / 11.0 13.0 / 11.0
Decibels 76 76 76 78 78
AHRI # 4635457 4635469 4635458 4635470 4635459
Type PSC PSC PSC PSC PSC
Wheel (D x W) 9 x 6 9 x 6 9 x 6 9 x 8 9 x 8
Nominal Cooling CFM 815 1,080 1,080 1,205 1,205
RLA / LRA 1.5 / 2.2 1.86 / 3.2 1.86 / 3.2 1.86 / 3.2 1.86 / 3.2
No. of Speeds 3 3 3 3 3
Horsepower - RPM ¼ - 952 ⅓ - 1,020 ⅓ - 1,020 ⅓ - 1,020 ⅓ - 1,020
Face Area (²) 4.6 4.6 4.6 5.2 5.2
Rows Deep / Fins per Inch 3 / 14 3 / 14 3 / 14 3 / 14 3 / 14
Filter Size (“) 20 x 20 x 1 20 x 25 x 1 20 x 25 x 1 25 x 25 x 1 25 x 25 x 1
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
Refrigerant Charge (oz.) 63 80 62 85 61
Horsepower - RPM ¹/6 - 815 ¼ - 830 ¹/6 - 815 ¼ - 830 ¼ - 830
RLA / LRA 1.1 / 1.7 1.5 / 3.0 1.1 / 1.7 1.5 / 3.0 1.5 / 3.0
Fan Diameter/ # Fan Blades 22 / 2 22 / 3 22 /2 22 /4 22 / 4
Face Area (²) 12.3 13.4 12.3 13.4 12.3
Rows Deep / Fins per Inch 1 / 26 1 / 24 1 / 26 1 / 24 1 / 26
Quanty 1 1 1 1 1
Type Scroll Recip Scroll Scroll Scroll
Stage Single Single Single Single Single
Compressor RLA / LRA 13.5 / 58.3 9.8 / 55 12.8 / 64 16.7 / 79 16.7 / 79
Voltage-Phase 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1
Indoor Blower FLA 1.5 1.86 1.86 1.86 1.86
Outdoor Fan RLA 1.7 1.5 1.7 1.5 1.5
Total Unit Amps 16.1 13.16 15.76 20.06 20.06
Min. Circuit Ampacity¹ 19.5 15.6 19 24.2 24.2
Max. Overcurrent Protecon (amps)² 30 25 30 40 40
290 310 290 370 370
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
