PRODUCT DESIGN
17
SUCTION
PRESSURE
SATURATED
SUCTION
TEMPERATURE
ºF
LIQUID
PRESSURE
SATURATED
LIQUID
TEMPERATURE
ºF
PSIG R-410A PSIG R-410A
50 1 200 70
52 3 210 73
54 4 220 76
56 6 225 78
58 7 235 80
60 8 245 83
62 10 255 85
64 11 265 88
66 13 275 90
68 14 285 92
70 15 295 95
72 16 305 97
74 17 325 101
76 19 355 108
78 20 375 112
80 21 405 118
85 24 415 119
90 26 425 121
95 29 435 123
100 31 445 125
110 36 475 130
120 41 500 134
130 45 525 138
140 49 550 142
150 53 575 145
160 56 600 149
170 60 625 152
SATURATED
SUCTION PRESSURE
TEMPERATURE CHART
SATURATED
LIQUID PRESSURE
TEMPERATURE CHART
TABLE 6
Suction Pressure
Liquid Pressure
SUPERHEAT = SUCTION LINE TEMP - SAT. SUCTION
TEMP.
Model #
Superheat
±2°F
Supercooling ±2°F
GPC1524H41 6° ---
GPC1530H41 8° ---
GPC1536H41 12° ---
GPC1542H41 7° ---
GPC1548H41 10° ---
GPC1560h41 12° 12°
Model #
Superheat
±2°F
Supercooling ±2°F
GPH1524H41 15° 7°
GPH1530H41 15° 7°
GPH1536H41 10° 13°
GPH1542H41 12° 13°
GPH1548H41 15° 15°
GPC15
Design Superheat @ 95°F Outdoor Ambient
Temperature
GPH16
Design Superheat @ 95°F Outdoor Ambient
Temperature
