7. BASIC DISC PLAY
1. Slide the OPEN button to open the CD
compartment lid. Connect the earphones
to the earphone socket.
2. Adjust the VOLUME to minimum.
3. Insert the disc with the label side Facing up.
4. Push down in the centre until disc is locked
in place.
5. Close the lid gently until a click is heard.
6. Press the PLAY button to start playing. To
turn the power off, press the STOP Button
twice.
TO Emphasize the bass sound
Set the BASS BOOST switch to the right
position.
To Pause playback of the CD Press the
PLAY/PAUSE button, the current track
elapsed will flash in the display and the
audio output will be muted. To resume
playback press PLAY/PAUSE again.
time
The bass boost performance will be
dependant on the VOLUME control setting.
Remove the disc
Hold the edge and gently press the centre
pivot as illustrated. then pick up the disc.
Note
Note
6. PRODUCT SPECIFICATIONS
Bass boost effect
(100HZ)
Weight
Dimension
Power consumption
Power requirements
Output level
Anti-shock
No. of channels
Wow and flutter
Frequency response
D/A conversion
+8dB.
Approx. 230g not including battery (Main Unit)
Approx. 136(W) x 31.5(H) x 151.5(D)mm
0.8W (DC 6V) UNDER NORMAL CONDITION
- DC in socket accepts AC power adaptor, type 16A only.
- 2 x "AA" alkaline battery
)
(3218mW 0.2mWEarphone:
)
(47KrmsV0.5 V 0.1Voutput:Line
45 seconds buffer
2 channels (stereo)
Below measurable limits
20-20,000Hz (+1/-3 dB)
1-bit DAC 8 times oversampling
AUDIO
GENERAL
System
Cross-interleave Reed-solomon code
material: GaAIAs
Compact disc digital audio system
Error correction
Properties
Laser diode
PICK-UP
Laser output: <44.6 W
Emission Duration: continuous
=780nm
Wavelength:
OFF BASS ON
BOOST
+
-
+
-
CAUTION:
Wait for the disc to stop rotating before
pressing the OPEN button.
This unit can play 3" (8cm) single CD's
without an adaptor. Do not use a CD single
adaptor for these discs.
Note
Note
Only compact discs marked with the disc logo
are guaranteed to work on this player. Home
recorded discs (CDR) recorded on home pc's
may not play or operate correctly.
