Goodwe BCL9600 User Manual

1
User Manual V1.1-2022-06-30 01 Introduction
The Battery Enclosure dimensions are: width 516mm, depth 280mm, height 1155mm (without
the feet installed) and width 516mm, depth 280mm, height 1205mm (with the feet installed).
516mm
1205mm 1205mm
280mm
Figure 1: Dimensions
1.2 Parts List
1.1 Dimensions
01 Product Introduction
Expansion
bolts x N
Short grounding
wire x 4
Long grounding
wire x 1
Ground screw xN
Glue x 1
Base screw x N
Signal Cable x 1
Documents x 1
Hexagon screw
of top cover x 4
Countersunk
screw x N
Base x 2Lock bracket x 4
N = Quantity depends on the product model.
