Goodwe DNS User Manual

09
6.5mm
25mm
2
CT
CT
1
3
2
CT
DRED
6: DRM1/5
5: DRM2/6
4: DRM3/7
3: DRM4/8
2: REFGEN
1: COM/DRM0
6
5
4
3
2
1
M3
0.8N·m
4
DRED
DRED
DRED
Remote
Shutdown
6: Reserved
5: Reserved
4: Reserved
3: DRM4/8
2: REFGEN
1: Reserved
3
3
3
3
4
4
4
4
4
1
4
DRED
CT
6.5mm
25mm
1
DRED
CT
3
DRED
CT
1
2: CT+
1: CT-
2
1
M3
0.8N·m
4
2
4
4
4
4
2
CT
DRED
3
3
3
3
4
1
4
Connecting the DRED/Remote Shutdown Communication Cable (Optional)
Connecting the CT Communication Cable (Optional)
Contattheafter-salesservicetogettheDREDterminalifyouneedtouseDREDfunction.
DREDfunctioniso󽗈bydefault.StartthisfunctionviaSolarGoAppifit'sneeded.

Goodwe DNS Specifications

General

Number of MPPTs	2
AC Voltage Range	180-280 V
Total Harmonic Distortion (THD)	< 3%
Euro Efficiency	97.5%
Protection Degree	IP65
Cooling Method	Natural Convection
DC Switch	Yes
Model	DNS
Nominal AC Voltage	230 V
Nominal Grid Frequency	50 Hz / 60 Hz
Power Factor	0.8 leading - 0.8 lagging
Operating Temperature Range	-25°C to 60°C
Communication	RS485
