Goodwe GW5000D-NS User Manual

06 Electrical Connection
17
User Manual V1.0-2022-12-15
NOTICE
Seal the PV input terminals using waterproof covers when they are not to be used. Otherwise,
the ingress protection rating will be inuenced.
Click
Step 1 Prepare DC cables.
Step 2 Crimp the crimp contacts.
Step 3 Disassemble the PV connectors.
Step 4 Make the DC cable and detect the DC input voltage.
Step 5 Plug the PV connectors into the PV terminals.
Connecting the DC Input Cable
Devalan PV connector
2.5mm
2
≤S≤4mm
2
