Gorilla Playsets Landing - Page 48

Step 19: Rock Wall
1. Locate ten 5/4 x 5 x 23-7/8” Rock Wall Boards and one 5/4 x 5 x 23-7/8” Bottom Rock
Wall Board with one big hole in it.
2. Place one Rock Wall Board at the top of the Rock Wall Sides nearest the holes where
you previously installed the tee nuts. Make sure the Rock Wall Board is ush with the
ends and sides of the Rock Wall Side boards.
3. Attach the Rock Wall Board with four 2” wood screws.
4. Now place another Rock Wall Board beneath the one previously installed and attach
with four 2” wood screws. Continue installing Rock Wall Boards to the Rock Wall Sides
until they are used up.
5. Attach the Bottom Rock Wall Board with one large hole in it last with four 2” wood
screws. The large hole should be offset up.
5/4 x 5 x 23-7/8”
Rock Wall Board
(Install this one rst)
2” Wood Screw
Flush
Flush
Flush
5/4 x 5 x 23-7/8”
Bottom Rock Wall Board
(big hole is offset up)
Page 48
®
