Step 40: Safety Board
This board is meant to be a visual deterrent to prevent children from running through the
base of the play set into other children on the swing set.
1: Measure 17-1/4” from the top of the Rear Sandbox Board and make a mark on the
rear corner posts.
2: Place the bottom of a 2 x 4 x 47-3/8” Panel Support with offset holes down on the
marks.
3: Attach the Panel Support to the rear corner posts with two 5/16” x 3-1/2” lag screws
and two 5/16” washers.
2 x 4 x 47-3/8”
Panel Support
5/16” x 3-1/2”
Lag screw
5/16” Washer
17-1/4”
Page 69
