Step 49: Ground Stakes
1: Drive the Ground Stakes into the ground so that approximately 4” of the stake is
above ground on the outside of the swing legs.
2: Use 5/16” x 3-1/2” lag screws and 5/16” washers to attach the Ground Stakes to the
swing legs.
3: Two more Ground Stakes will be on the inside of the sandbox on the two corner posts
closest to the slide. On the inside of the base of the play set drive the Ground Stakes
into the ground to a distance that will not interfere with the hex bolts that are installed in
the sandbox boards.
4: Use 5/16 x 3-1/2” lag screws and 5/16” washers to attach the Ground Stakes to the
corner posts.
5/16” Washer
5/16” x 3-1/2”
Lag Screw
Ground Stake
Ground Stake
5/16” x 3-1/2” Lag Screw
5/16” Washer
on the inside of this corner
post (partially obstructed
from view).
5/16” x 3-1/2”
Lag Screw
5/16” Washer
Ground Stake
Page 78
