38
D/A CONVERTER FIXED OUTPUTS all specications are subject to change
Output Levels
User selectable (0dBFS) -76dBu to +24dBu in 0.5dB steps
Fixed output trim range (0.5dB steps)
THD+N
1kHz, -1dBFS, (0dBFS = +20dBu), 20-22kHz bandwidth 0.0006%
Dynamic Range
20-22kHz bandwidth, 0dBFS = +20dBu (AES17 lter) 117dB
20-22kHz bandwidth, 0dBFS = +20dBu (A-weighted) 119dB
Input Lock Range
AES3/SPDIF
44.1kHz +/-400Hz
48kHz +/-700Hz
88.2kHz +/-1200Hz
96kHz +/-1300Hz
176.4kHz +/-2000Hz
192kHz +/-2000Hz
ADAT LIGHTPIPE™
44.1kHz +/-400Hz
48kHz +/-700Hz
88.2kHz +/-1200Hz
96kHz +/-1300Hz
ADAT LIGHTPIPE™
44.1kHz +/-50Hz
48kHz +/-70Hz
88.2kHz +/-50Hz
96kHz +/-70Hz
s-Lock™ Capture Range
44.1kHz +/- 6Hz
48 kHz +/- 7Hz
88.2 kHz +/- 14Hz
96 kHz +/- 20Hz
176.4 kHz +/- 24Hz
192 kHz +/- 30Hz
Word Clock / Superclock Input
Impedance (switchable) 75 ohm / 1Meg ohm
Minimum Voltage 3V peak to peak
Maximum Voltage 5V peak to peak
Word clock frequencies supported 44.1, 48, 88.2, 96, 176.4, 192kHz
Superclock frequencies supported N/A
USB Supported Sample Rates 44.1, 48, 88.2, 96, 176.4, 192kHz, DSD64 2.8224MHz, DSD128 5.6448MHz
POWER SUPPLY / GENERAL
Power consumption 60W
Input Voltage 100VAC – 240VAC / 50-60Hz
Dimensions
Main chassis IEC 2U 3.5” x 10.5” x 17”
Remote control unit 8.9” x 5.1” x 2.2”
Weight
Main chassis 7.8lbs
Remote control unit 2.2lbs
