40
18 PCB Jumper Locations
MAIN PCB JUMPER LOCATIONS
REAR PANEL
DIGITAL I/O PCB JUMPER LOCATION
J7: AES DUAL WIRE / ADAT SELECT
ADAT
AES 2 WIRE
REAR PANEL
