Grace Q'nique 15 User Manual

11
1. Place one of the Wheels on to the Upper
Encoder and screw it into the left rear
position on the Quilting Machine.
3. Twist the Lock Collar on the Upper Encoder
up to tighten the Spring. Tighten the Set
Screw using the 2mm Allen Wrench to
tension the Encoder.
2. Place the remaining Wheel in to the Lower
Encoder and screw it in to the rear left
position of the Bottom Carriage.
4. Twist the Lock Collar on the Lower Encoder
up to tighten the Spring. Tighten the Set
Screw using the 2mm Allen Wrench to
tension the Encoder.
Lower Encoder (Black Spring)
Lower Encoder (Black Spring)
Upper Encoder (Silver Spring)
Upper Encoder (Silver Spring)
Upper Encoder
(Silver Spring)
Wheel
Lower Encoder
(Black Spring)
Wheel
Twist Lock
Collar up
Tighten the Lock
Collar Set Screw
Tighten the Lock
Collar Set Screw
Twist Lock
Collar up
Lower Encoder
(Black Spring)
Upper Encoder
(Silver Spring)
