35
The Needle Plate
1. Place your Needle Plate on your Quilting Machine and rotate Hand Wheel to lower Needle and
ensure Needle Plate orientation. Ensure all screw holes are visible and Needle enters the middle of
the Needle Plate without contacting the Needle Plate at any point.
2. Attach your Needle Plate using 4 Needle Plate Screws, don’t tighten the screws during this step.
3. Rotate hand wheel until the Needle is in the lowest position move Needle Plate till it is centered
around Needle and tighten all 4 Needle Plate Screws.
Flat Head
Screw Driver
Parts & Tools Needed:
Needle Plate
Needle Plate Screw
Needle
