Plugging In The Cables
1. Once all the components are connected, you can attach the Power Cord to the Quilting Machine,
then connect the Power Cord to an outlet.
2. When you are ready to begin sewing, turn on the machine using the power switch located on the
back of the machine.
Below is a reference of how the machine should be congured.
» Encoder
» Encoder
» Foot Pedal
» Quilt Motion Control
» USB Connector Port
On
Power
Adapter
Power
Cord
Quilt Motion
Tablet
Short
Encoder
Cable
Long
Encoder
cable
(For sit down system)
(Programming only)
(For optional Automation Accessory)
O
To Next Page
