20
Winding The Bobbin
1. Pass the thread through the (2) Guide Loops
on the Thread Mast.
3. Loop the thread around the Spring Hook and
around the Thread Tensioner.
2. Pull the thread through both holes in the Bob-
bin Thread Guide.
4. Wrap the thread around the Bobbin as shown.
5. Start the Bobbin Winder by pushing the Bob-
bin Winder Cam into the Bobbin.
Note: When the Bobbin is full it will automatically
stop.
Adjust the Cam to adjust bobbin ll.
Thread
Mast
Push Bobbin
Winder Cam
Bobbin
Thread
Tensioner
Bobbin Thread
Guide
Spring Hook
Guide
Loop
To Next Page
