Graco 17D889 TrueCoat 360 VSP User Manual

Replacement Parts
333394H 25
Parts List- Model 17D889
Ref.
If you have this
model sprayer
Order
Part
Number
Description
1 Kit, pump
17D889 17B415 Complete pump assembly includes 2, 3, 4, 5, 6, 7, 8
17D889 17B416 Pump housing includes 2, 3, 5
2 All models 16Y425 O-ring
3 All models 16W849 Strainer
4 All models 17A219 Kit, needle assembly includes 5 and spray tip 17A222
5 All models 17A220 Kit, pump outlet
6 All models 17A402 Prime Pump/Spray valve
7 All models 17A221 Kit, Prime Pump/Spray knob includes qty. 1 of ref. 8
8 All models 119236 Screw, T-15 (torque 8-10 in-lb / 0.9-1.1 N
•m)
9 All models 17A223 Spray tips, (black/12-inch pattern, gray/4-inch pattern)
10 All models 16X880 Reciprocator assembly
12 17D889 17F068 Control, electronic includes motor, power cord and switch
Variable speed, 120 V
13 17D889 17D844 Adapter, variable speed control
14 17D889 17D850 Support, cup, 42 oz.
15 17D889 17F005 Kit, 42 oz., FlexLiner (3-pack)
16 All models 17B636 Cover, cup
17 All models 115719 O-ring
18 All models 16X806 VacuValve cap
19 17D889 17A649 Kit, enclosure gray includes qty. 13 of ref. 8
20 All models 16Y680 Label, USA
22 All models 16Y678 Label, control
23  All models 16Y636 Label, warning and model number, side (not shown)
24 17D889 17F154 Label, brand, TrueCoat 360 VSP
25  All models 17A198 Label, warning, cord (not shown)
26 17D889 17C468 Case, storage
27 17D889 17F069 Kit, enclosure, variable speed includes sight glass,
includes 13, 29, qty. 2 of ref 8
28 17D889 17F364 Kickstand
29 17D889 17D843 Sight glass
All models 17F518 Kit, 42 oz. cup includes 14, 15, 28
- - - 243104 Pump Armor, not shipped with sprayer 32 oz (not shown)
 Replacement Danger and Warning labels, tags, and cards are available at no cost.
