If either end of the spring
(16)
is worn or damaged and
does not hook properly on the reel hub (15) or the pin
(H)
which is welded to the inside of the lower reel flange (13),
replace the spring. See Fig 9. If the pin is broken, the lower
reel flange must be replaced.
To
remove the spring,
use
a locking pliers
(J)
to compress
several rows ofthe spring together. Then lift
out
the spring.
See Fig 9.
Before
disposingofthespring, carefullyattach aminimum
of two hose
clamps around the keeper and spring bands
as shown
in
Fig 10.
Use a locking pliers
(J)
to compress several rows of the
spring together when greasing and installing the new
spring.Coatthenewspringandtheflangewithamu1ti-pur-
pose, lithium-based grease before installing the spring.
spring hooks the reel hub
(15),
and the outside end of the
Install the new spring making
sure the inside end of the
spring hooks the pin
(H).
See
Fig 9.
\
HOSE
KEEPER
C~MP
Flg
lo
Retract the hose as far as
the
hose stop
to
release the
springtension.
Removethereelfromthepedestal(l).This
exposes the latch. Replace all wom or damaged parts and
reassemble the reel.
Applytwo drops of light weight motor
oil to points
C
and 40. See Fig 11.
Latch
1-
CAUTION
To
avoid damage to the reel and
to
avoid a
malfunction of the reel, do not modify the latch arm
spring (37). When replacing the spring, order and
use, Graco Part
No.
107
-
440, only.
If
the reel latch (21) fails
to
latch, replace the latching
mechanism.
307
-
694
19
