22 308118
Technical Data (10:1 President)
Category Data
Maximum fluid working pressure 1800 psi (12.4 MPa, 124 bar)
Maximum air input pressure 180 psi (1.25 MPa, 12.5 bar)
Pump cycles per 1 gallon (3.8 liters) 20
Fluidflowat60cpm 3 gallon (11.4 liters)
Recommended speed for optimum
pump life
15--25 cycles/min;
0.75--1.25 gpm (2.84 to 4.73 liters/min)
Air consumption approx. 15 scfm (0.42 m
3
/min) at 1 gpm (3.8 liters/min)
at 100 psi (0.7 MPa, 7 bar) air pressure
Weight approx. 43 lb (19.5 kg)
Wetted parts AISI 302, 303, 304, 316, and 17--4 PH grades of Stainless Steel;
Chrome Plating; PTFE; Ultra-High Molecular Weight Polyethylene
